When I launch the flowable/all-in-one image:
# docker pull flowable/all-in-one
docker run -d --name flowable \
-p 8080:8080 \
--env-file ldap-env.txt \
flowable/all-in-one
And then check the logs:
docker logs flowable
Output:
////////// &&&& &&& ,,, ,,,
////////////// &&&&&&& &&& ,,, ,,,
/// /// &&& &&& ,,, ,,,
//////// /// &&&&&&&& &&& &&&&&&& &&& &&& &&& ,,,,,,,,,, ,,,,,,,,, ,,, ,,,,,,,
////// // /// &&&&&&&& &&& &&&& &&&& &&& &&& &&& ,,, ,,,, ,,,, ,,,, ,,, ,,, ,,
/// //// /// &&& &&& &&& &&& &&& &&& &&& ,, ,,, ,,, ,,, ,,, ,,,,,,,,,
// ///// /// &&& &&& &&& &&&& &&& &&& &&& ,,, ,,,, ,,,, ,,, ,,, ,,,
/////////// &&& &&& &&&&&&&& &&&&&&&&&&&&&& ,,,,,,,,,, ,,,,,,,, ,,, ,,,,,,,,
:: Flowable :: (v6.5.0-SNAPSHOT) :: Spring Boot :: (v2.2.2.RELEASE)
2020-01-07 02:23:53.715 INFO 1 --- [ main] o.f.u.m.a.FlowableModelerApplication : Starting FlowableModelerApplication v6.5.0-SNAPSHOT on 25d7e898c602 with PID 1 (/opt/tomcat/webapps/flowable-modeler/WEB-INF/classes started by tomcat in /opt/tomcat)
2020-01-07 02:23:53.735 INFO 1 --- [ main] o.f.u.m.a.FlowableModelerApplication : No active profile set, falling back to default profiles: default
2020-01-07 02:23:56.519 INFO 1 --- [ main] trationDelegate$BeanPostProcessorChecker : Bean 'org.springframework.transaction.annotation.ProxyTransactionManagementConfiguration' of type [org.springframework.transaction.annotation.ProxyTransactionManagementConfiguration] is not eligible for getting processed by all BeanPostProcessors (for example: not eligible for auto-proxying)
2020-01-07 02:23:56.564 INFO 1 --- [ main] o.s.w.c.ContextLoader : Root WebApplicationContext: initialization completed in 2542 ms
2020-01-07 02:23:56.665 WARN 1 --- [ main] uration$JodaDateTimeJacksonConfiguration : Auto-configuration of Jackson's Joda-Time integration is deprecated in favor of using java.time (JSR-310).
2020-01-07 02:23:57.537 INFO 1 --- [ main] c.z.h.HikariDataSource : flowable-ui-modeler - Starting...
2020-01-07 02:23:57.979 INFO 1 --- [ main] c.z.h.HikariDataSource : flowable-ui-modeler - Start completed.
2020-01-07 02:23:57.992 INFO 1 --- [ main] o.f.u.m.c.DatabaseConfiguration : database product name: 'H2'
2020-01-07 02:23:57.993 INFO 1 --- [ main] o.f.u.m.c.DatabaseConfiguration : using database type: h2
2020-01-07 02:23:58.933 INFO 1 --- [ main] o.f.u.m.c.DatabaseConfiguration : Configuring Liquibase
2020-01-07 02:23:59.639 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT COUNT(*) FROM PUBLIC.ACT_DE_DATABASECHANGELOGLOCK
2020-01-07 02:23:59.656 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE TABLE PUBLIC.ACT_DE_DATABASECHANGELOGLOCK (ID INT NOT NULL, LOCKED BOOLEAN NOT NULL, LOCKGRANTED TIMESTAMP, LOCKEDBY VARCHAR(255), CONSTRAINT PK_ACT_DE_DATABASECHANGELOGLOCK PRIMARY KEY (ID))
2020-01-07 02:23:59.660 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT COUNT(*) FROM PUBLIC.ACT_DE_DATABASECHANGELOGLOCK
2020-01-07 02:23:59.664 INFO 1 --- [ main] l.e.j.JdbcExecutor : DELETE FROM PUBLIC.ACT_DE_DATABASECHANGELOGLOCK
2020-01-07 02:23:59.665 INFO 1 --- [ main] l.e.j.JdbcExecutor : INSERT INTO PUBLIC.ACT_DE_DATABASECHANGELOGLOCK (ID, LOCKED) VALUES (1, FALSE)
2020-01-07 02:23:59.667 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT LOCKED FROM PUBLIC.ACT_DE_DATABASECHANGELOGLOCK WHERE ID=1
2020-01-07 02:23:59.676 INFO 1 --- [ main] l.l.StandardLockService : Successfully acquired change log lock
2020-01-07 02:24:00.854 INFO 1 --- [ main] l.c.StandardChangeLogHistoryService : Creating database history table with name: PUBLIC.ACT_DE_DATABASECHANGELOG
2020-01-07 02:24:00.855 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE TABLE PUBLIC.ACT_DE_DATABASECHANGELOG (ID VARCHAR(255) NOT NULL, AUTHOR VARCHAR(255) NOT NULL, FILENAME VARCHAR(255) NOT NULL, DATEEXECUTED TIMESTAMP NOT NULL, ORDEREXECUTED INT NOT NULL, EXECTYPE VARCHAR(10) NOT NULL, MD5SUM VARCHAR(35), DESCRIPTION VARCHAR(255), COMMENTS VARCHAR(255), TAG VARCHAR(255), LIQUIBASE VARCHAR(20), CONTEXTS VARCHAR(255), LABELS VARCHAR(255), DEPLOYMENT_ID VARCHAR(10))
2020-01-07 02:24:00.857 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT COUNT(*) FROM PUBLIC.ACT_DE_DATABASECHANGELOG
2020-01-07 02:24:00.857 INFO 1 --- [ main] l.c.StandardChangeLogHistoryService : Reading from PUBLIC.ACT_DE_DATABASECHANGELOG
2020-01-07 02:24:00.858 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT * FROM PUBLIC.ACT_DE_DATABASECHANGELOG ORDER BY DATEEXECUTED ASC, ORDEREXECUTED ASC
2020-01-07 02:24:00.859 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT COUNT(*) FROM PUBLIC.ACT_DE_DATABASECHANGELOGLOCK
2020-01-07 02:24:00.920 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE TABLE PUBLIC.ACT_DE_MODEL (id VARCHAR(255) NOT NULL, name VARCHAR(400) NOT NULL, model_key VARCHAR(400) NOT NULL, description VARCHAR(4000), model_comment VARCHAR(4000), created TIMESTAMP, created_by VARCHAR(255), last_updated TIMESTAMP, last_updated_by VARCHAR(255), version INT, model_editor_json CLOB, thumbnail BLOB, model_type INT, CONSTRAINT PK_ACT_DE_MODEL PRIMARY KEY (id))
2020-01-07 02:24:00.925 INFO 1 --- [ main] l.c.ChangeSet : Table ACT_DE_MODEL created
2020-01-07 02:24:00.926 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE INDEX PUBLIC.idx_proc_mod_created ON PUBLIC.ACT_DE_MODEL(created_by)
2020-01-07 02:24:00.928 INFO 1 --- [ main] l.c.ChangeSet : Index idx_proc_mod_created created
2020-01-07 02:24:00.929 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE TABLE PUBLIC.ACT_DE_MODEL_HISTORY (id VARCHAR(255) NOT NULL, name VARCHAR(400) NOT NULL, model_key VARCHAR(400) NOT NULL, description VARCHAR(4000), model_comment VARCHAR(4000), created TIMESTAMP, created_by VARCHAR(255), last_updated TIMESTAMP, last_updated_by VARCHAR(255), removal_date TIMESTAMP, version INT, model_editor_json CLOB, model_id VARCHAR(255) NOT NULL, model_type INT, CONSTRAINT PK_ACT_DE_MODEL_HISTORY PRIMARY KEY (id))
2020-01-07 02:24:00.932 INFO 1 --- [ main] l.c.ChangeSet : Table ACT_DE_MODEL_HISTORY created
2020-01-07 02:24:00.932 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE INDEX PUBLIC.idx_proc_mod_history_proc ON PUBLIC.ACT_DE_MODEL_HISTORY(model_id)
2020-01-07 02:24:00.933 INFO 1 --- [ main] l.c.ChangeSet : Index idx_proc_mod_history_proc created
2020-01-07 02:24:00.934 INFO 1 --- [ main] l.e.j.JdbcExecutor : CREATE TABLE PUBLIC.ACT_DE_MODEL_RELATION (id VARCHAR(255) NOT NULL, parent_model_id VARCHAR(255), model_id VARCHAR(255), relation_type VARCHAR(255), CONSTRAINT PK_ACT_DE_MODEL_RELATION PRIMARY KEY (id))
2020-01-07 02:24:00.935 INFO 1 --- [ main] l.c.ChangeSet : Table ACT_DE_MODEL_RELATION created
2020-01-07 02:24:00.936 INFO 1 --- [ main] l.e.j.JdbcExecutor : ALTER TABLE PUBLIC.ACT_DE_MODEL_RELATION ADD CONSTRAINT fk_relation_parent FOREIGN KEY (parent_model_id) REFERENCES PUBLIC.ACT_DE_MODEL (id)
2020-01-07 02:24:00.945 INFO 1 --- [ main] l.c.ChangeSet : Foreign key constraint added to ACT_DE_MODEL_RELATION (parent_model_id)
2020-01-07 02:24:00.946 INFO 1 --- [ main] l.e.j.JdbcExecutor : ALTER TABLE PUBLIC.ACT_DE_MODEL_RELATION ADD CONSTRAINT fk_relation_child FOREIGN KEY (model_id) REFERENCES PUBLIC.ACT_DE_MODEL (id)
2020-01-07 02:24:00.948 INFO 1 --- [ main] l.c.ChangeSet : Foreign key constraint added to ACT_DE_MODEL_RELATION (model_id)
2020-01-07 02:24:00.948 INFO 1 --- [ main] l.c.ChangeSet : ChangeSet META-INF/liquibase/flowable-modeler-app-db-changelog.xml::1::flowable ran successfully in 34ms
2020-01-07 02:24:00.950 INFO 1 --- [ main] l.e.j.JdbcExecutor : SELECT MAX(ORDEREXECUTED) FROM PUBLIC.ACT_DE_DATABASECHANGELOG
2020-01-07 02:24:00.961 INFO 1 --- [ main] l.e.j.JdbcExecutor : INSERT INTO PUBLIC.ACT_DE_DATABASECHANGELOG (ID, AUTHOR, FILENAME, DATEEXECUTED, ORDEREXECUTED, MD5SUM, DESCRIPTION, COMMENTS, EXECTYPE, CONTEXTS, LABELS, LIQUIBASE, DEPLOYMENT_ID) VALUES ('1', 'flowable', 'META-INF/liquibase/flowable-modeler-app-db-changelog.xml', NOW(), 1, '8:e70d1d9d3899a734296b2514ccc71501', 'createTable tableName=ACT_DE_MODEL; createIndex indexName=idx_proc_mod_created, tableName=ACT_DE_MODEL; createTable tableName=ACT_DE_MODEL_HISTORY; createIndex indexName=idx_proc_mod_history_proc, tableName=ACT_DE_MODEL_HISTORY; createTable tableN...', '', 'EXECUTED', NULL, NULL, '3.8.0', '8363840859')
2020-01-07 02:24:00.964 INFO 1 --- [ main] l.e.j.JdbcExecutor : ALTER TABLE PUBLIC.ACT_DE_MODEL ADD tenant_id VARCHAR(255)
2020-01-07 02:24:00.976 INFO 1 --- [ main] l.c.ChangeSet : Columns tenant_id(varchar(255)) added to ACT_DE_MODEL
2020-01-07 02:24:00.977 INFO 1 --- [ main] l.e.j.JdbcExecutor : ALTER TABLE PUBLIC.ACT_DE_MODEL_HISTORY ADD tenant_id VARCHAR(255)
2020-01-07 02:24:00.982 INFO 1 --- [ main] l.c.ChangeSet : Columns tenant_id(varchar(255)) added to ACT_DE_MODEL_HISTORY
2020-01-07 02:24:00.982 INFO 1 --- [ main] l.c.ChangeSet : ChangeSet META-INF/liquibase/flowable-modeler-app-db-changelog.xml::3::flowable ran successfully in 19ms
2020-01-07 02:24:00.984 INFO 1 --- [ main] l.e.j.JdbcExecutor : INSERT INTO PUBLIC.ACT_DE_DATABASECHANGELOG (ID, AUTHOR, FILENAME, DATEEXECUTED, ORDEREXECUTED, MD5SUM, DESCRIPTION, COMMENTS, EXECTYPE, CONTEXTS, LABELS, LIQUIBASE, DEPLOYMENT_ID) VALUES ('3', 'flowable', 'META-INF/liquibase/flowable-modeler-app-db-changelog.xml', NOW(), 2, '8:3a9143bef2e45f2316231cc1369138b6', 'addColumn tableName=ACT_DE_MODEL; addColumn tableName=ACT_DE_MODEL_HISTORY', '', 'EXECUTED', NULL, NULL, '3.8.0', '8363840859')
2020-01-07 02:24:00.986 INFO 1 --- [ main] l.l.StandardLockService : Successfully released change log lock
2020-01-07 02:24:01.370 INFO 1 --- [ main] o.s.s.w.DefaultSecurityFilterChain : Creating filter chain: Ant [pattern='/api/**'], [org.springframework.security.web.context.request.async.WebAsyncManagerIntegrationFilter@5b3d20cc, org.springframework.security.web.context.SecurityContextPersistenceFilter@1b621efe, org.springframework.security.web.header.HeaderWriterFilter@79ed2670, org.springframework.security.web.authentication.logout.LogoutFilter@452946df, org.springframework.security.web.authentication.www.BasicAuthenticationFilter@632fce34, org.springframework.security.web.savedrequest.RequestCacheAwareFilter@65cb9158, org.springframework.security.web.servletapi.SecurityContextHolderAwareRequestFilter@4e51d06e, org.springframework.security.web.authentication.AnonymousAuthenticationFilter@2f94abcc, org.springframework.security.web.session.SessionManagementFilter@783f8e9b, org.springframework.security.web.access.ExceptionTranslationFilter@71e70f8d, org.springframework.security.web.access.intercept.FilterSecurityInterceptor@24415283]
2020-01-07 02:24:01.384 INFO 1 --- [ main] o.s.s.w.DefaultSecurityFilterChain : Creating filter chain: org.flowable.ui.common.security.ActuatorRequestMatcher@1b3d68b6, [org.springframework.security.web.context.request.async.WebAsyncManagerIntegrationFilter@5c33ab81, org.springframework.security.web.context.SecurityContextPersistenceFilter@4d0cb2c5, org.springframework.security.web.header.HeaderWriterFilter@526d278, org.springframework.security.web.authentication.logout.LogoutFilter@23d06658, org.springframework.security.web.authentication.www.BasicAuthenticationFilter@77f0b0de, org.springframework.security.web.savedrequest.RequestCacheAwareFilter@2189ac45, org.springframework.security.web.servletapi.SecurityContextHolderAwareRequestFilter@128f0f1e, org.springframework.security.web.authentication.AnonymousAuthenticationFilter@558c3671, org.springframework.security.web.session.SessionManagementFilter@13814eba, org.springframework.security.web.access.ExceptionTranslationFilter@14df06df, org.springframework.security.web.access.intercept.FilterSecurityInterceptor@2d349056]
2020-01-07 02:24:01.388 INFO 1 --- [ main] o.s.s.w.DefaultSecurityFilterChain : Creating filter chain: any request, [org.springframework.security.web.context.request.async.WebAsyncManagerIntegrationFilter@3f2919c7, org.springframework.security.web.context.SecurityContextPersistenceFilter@f51c595, org.springframework.security.web.header.HeaderWriterFilter@7f475bd5, org.springframework.security.web.authentication.logout.LogoutFilter@4411aea2, org.flowable.ui.common.filter.FlowableCookieFilter@7f8510d3, org.springframework.security.web.savedrequest.RequestCacheAwareFilter@41717985, org.springframework.security.web.servletapi.SecurityContextHolderAwareRequestFilter@4ad1b8d, org.springframework.security.web.authentication.AnonymousAuthenticationFilter@7a4c28d, org.springframework.security.web.session.SessionManagementFilter@78a724c3, org.springframework.security.web.access.ExceptionTranslationFilter@72b79b29, org.springframework.security.web.access.intercept.FilterSecurityInterceptor@3a4d2ad]
2020-01-07 02:24:01.983 INFO 1 --- [ main] o.s.s.c.ThreadPoolTaskExecutor : Initializing ExecutorService 'applicationTaskExecutor'
2020-01-07 02:24:02.158 INFO 1 --- [ main] o.s.b.a.w.s.WelcomePageHandlerMapping : Adding welcome page: class path resource [static/index.html]
2020-01-07 02:24:02.414 INFO 1 --- [ main] o.s.b.a.e.w.EndpointLinksResolver : Exposing 13 endpoint(s) beneath base path '/actuator'
2020-01-07 02:24:02.592 INFO 1 --- [ main] o.f.u.m.a.FlowableModelerApplication : Started FlowableModelerApplication in 9.871 seconds (JVM running for 15.411)
2020-01-07 02:24:02.768 INFO 1 --- [ main] o.s.w.s.DispatcherServlet : Initializing Servlet 'Flowable Modeler App API Servlet'
2020-01-07 02:24:02.865 INFO 1 --- [ main] o.s.w.s.DispatcherServlet : Completed initialization in 97 ms
...
There is no mention of REST API endpoints?
Try:
curl -i 'http://flowable:test@localhost:8080/flowable-task/process-api/identity/users/rob.ferguson'
Output:
{
"message": "Not found",
"exception": "Could not find a user with id 'rob.ferguson'."
}
Try:
curl -i 'http://flowable:test@localhost:8080/flowable-task/process-api/runtime/tasks?assignee=rob.ferguson'
Output:
{
"data": [
{
"id": "c3a48b57-30f6-11ea-806d-0242ac110004",
"url": "http://localhost:8080/flowable-task/process-api/runtime/tasks/c3a48b57-30f6-11ea-806d-0242ac110004",
"owner": null,
"assignee": "rob.ferguson",
"delegationState": null,
"name": "My First Task",
"description": "My first Flowable task",
"createTime": "2020-01-07T02:38:19.062Z",
"dueDate": null,
"priority": 50,
"suspended": false,
"claimTime": null,
"taskDefinitionKey": null,
"scopeDefinitionId": null,
"scopeId": null,
"scopeType": null,
"tenantId": "",
"category": null,
"formKey": null,
"parentTaskId": null,
"parentTaskUrl": null,
"executionId": null,
"executionUrl": null,
"processInstanceId": null,
"processInstanceUrl": null,
"processDefinitionId": null,
"processDefinitionUrl": null,
"variables": []
}
],
"total": 1,
"start": 0,
"sort": "id",
"order": "asc",
"size": 1
}
Try:
curl -i 'http://flowable:test@localhost:8080/flowable-task/process-api/identity/users/c3a48b57-30f6-11ea-806d-0242ac110004'
Output:
{
"message": "Not found",
"exception": "Could not find a user with id 'c3a48b57-30f6-11ea-806d-0242ac110004'."
}
See: Flowable Issue: 1958 - flowable/all-in-one Docker image missing REST API endpoints
